DDS3666
YONY OR OEM ODM
Single Phase 2 Module Din Rail Energy Meter (WIFI)
1. Introduction Modular DIN Rail Products offer a wide range of functions to be integrated in electrical installations with significant benefits for the user, complete range of DIN-mounted electricity Meters together with communication options. It is designed for high level performance, safe and convenient to install.
2.Technical Parameters
Model No. DDS3666
Casing ABS Anti Flaming material
Rated Voltage 230V Rated Current 10-60A Accuracy Class 1
Starting current 0.004Ib Impulse constant 1200imp/kWh
Frequency 50Hz / 60Hz Certificate CE
Standard IEC62052-11 ; IEC62053-21
Display LCD 6+1 = 999999.9
Power consumption ≤8VA ≤0.4W
Communication TUYA WIFI
Parameters Voltage, Current, Power, kWh
3. TUYA WIFI CONNECITON
1. Download from app store and register
2. Find device, make sure the device is power on and hold the button till the LED is flashing, cellphone match ( you need open the bluetooth and wifi service )
3. App will automatically add the device into the list, for this step it will take 1 mins
4. App has function of power on and off, if device you brought embed with latching relay
5. App can also make the meter as prepaid meter, only the Administrator cellphone can recharge the meter, after the money is used up the device will autocratically power off, until more money is recharged, it can used in rent house
6. The voltage current and power will show directly on the first page
7. More function you will find in the app, above is main
