DTS3666 DSS3666
YONY
Features of 3 Phase 220V 230V 240V Remote Watt Meter
The energy meter typically has a digital display that shows the current energy consumption and can also store historical energy consumption data. Some models also have communication ports that allow for remote monitoring and data retrieval.
Three-phase DIN rail energy meters are available in different accuracy classes, ranging Class 1 to Class 0.5, with Class 0.5 providing the highest level of accuracy. They are also available in different current ratings to suit different applications.
Specification | DTS3666 | |
Accuracy | Active | Class1.0 |
Reactive | Optional | |
Voltage | Rated | 3x57.7/100V,3x220/380V |
3x230/400V,3x240/415V | ||
Range | 0.9Un~1.1Un | |
Limit | 0.8Un~1.2Un | |
Frequency | 50/60Hz | |
Current | Range | 3x1.5(6), 3x 5(30), 3x 10(50), |
3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A | ||
Starting Current | 0.4%Ib | |
Constant | Active | 1600imp/kWh |
Reactive | \ | |
Display | Type | LCD |
Digit | 6+1 | |
Power Consumption | Voltage Circuit | ≤0.8W,10VA |
Current Circuit | ≤4VA | |
Communication | Interface | Optical/Infrared/RS485 (Optional) |
Protocol | MODBUS,DLT/645,IEC1107 | |
Temperature | Working Temperature | -45℃~+55℃ |
Storage Temperature | -40℃~+70℃ | |
Humidity | ≤90% | |
Protection | IP54 |
